Control Panel Mount
CPM87S-C Cable Tie Mount
CPM87S-C
Ensure a reliable connections with our control panel mount. Ideal for high-strain areas, they secure cables behind switches, enhancing durability and compatibility with most designs.
Select product to view details, compare, or add to list:
Specifications
| Note | Installed behind control panel switch. Compatible with most control panel switch designs. |
| Product Type | Cable Tie Mount |
| Application | (1) Installed Behind Control Panel Switch(2) Ideal for High Strain Areas Where Cable Is Routed From Panel To Panel Door(3) Compatible With Most Control Panel Switch Designs |
| Color | Silver |
| Environment | Indoor |
| Material | Steel/Zinc |
| Minimum Loop Tensile Strength (N) | 222 |
| Minimum Loop Tensile Strength (lb) | 50 |
| Mount Method | Screw-On |
| Overall Length (In.) | 2 |
| Overall Length (mm) | 51.1 |
| Overall Width (In.) | 1.1 |
| Overall Width (mm) | 28.8 |
| Overall Height (In.) | 0.16 |
| Overall Height (mm) | 4.2 |
| Standards Met | CE Compliant, RoHS Compliant |
| For Use With | Miniature, Intermediate, Standard Cable Ties |
Runtime Graph
| Configuration |
|---|
Packaging Detail
| UPC | 07498360085 |
| Std. Pkg. Qty. | 100 |
| Std. Pkg. Volume (cf) | 0.0334 |
| Std. Ctn. Qty. | 1000 |
| Std. Ctn. Volume (cf) | 0.3338 |
Resources
NOTE: Not all resources are available in your language.
If product info is not displayed in your selected language, it will be coming. We will continue to improve the experience over time.
Language
| Product Bulletins | Smart Control Panel Solutions - CPCB232 | English | |
| Videos | Cable Accesories Overview Video 16:9 | English | |
| Part Drawings | Part Drawing - PDF - CPM_1 | English | |
| Brochures Non Product | Soluciones para Panel de Control Inteligente CPCB232--SA-SPA | Spanish (Español) |
