Contour Crimp™ CT-1000 Ferrule Crimp Tool
Contour Crimp™ CT-1000 Crimp Tool, Dieless, 14-20 AWG, PK1
CT-1000
Our crimp tool features a trapezoid profile and rapid load design, reducing installation time. Its controlled-cycle mechanism ensures consistent, high-quality terminations.
Specifications
| Crimp Profile | Trapezoid |
| Tool Type | Dieless |
| Base Material | Plastic |
| Compatible Connector | FSD-DSL series Ferrules on strip |
| Sub Brand | Contour Crimp™ |
| Tool Configuration | Multi-function |
| Overall Length (In.) | 8.25 |
| Overall Length (mm) | 210 |
| Overall Width (In.) | 4.05 |
| Overall Width (mm) | 102.9 |
| Overall Height (In.) | 1.25 |
| Overall Height (mm) | 31.8 |
| Weight (Kg) | 0.2 |
| Weight (lb) | 548.95 |
| Product Type | Controlled Cycle Crimp Tool |
| Maximum Wire Size (AWG) | #14 |
| Minimum Wire Size (AWG) | #20 |
| Part Features | TOOL WEIGHT: (WITHOUT FERRULES) 8.8 Oz (0,249 kg) CRIMPS ALL STRIP FERRULE SIZES (MM2): 2,5; 1,5—1,0; 0,75–0,5 THIS TOOL’S FEATURES INCLUDE: • EASY TOP LOADING OF STRIP FERRULES • ADJUSTMENT KNOB TO SET FERRULES INTO CROSS SECTION SLOT • EASY CRIMPING OF FERRULES ON THE STRIPPED WIRE • STRIP AND CUT-OF CAPABILITIES WITH THE CUT-OFF BLADE AND COMPLETE HAND CYCLE • TOOL SPRING RETURNED TO OPEN POSITION AFTER CRIMPING DIMENSIONS SHOWN IN PARENTHESES ARE (MM) METRIC (WITHOUT FERRULES). A = 8.25 (210,00) OVERALL LENGTH B = 1.17 (29,85) OVERALL DIAMETER C = 1.25 (31,75) OVERALL DEPTH D = 4.05 (102,87) TOTAL HANDLE SPAN E = 0.65 (16,51) REAR HANDLE HEIGHT F = 0.86 (21,84) HANDLE WIDTH |
Runtime Graph
| Configuration |
|---|
Packaging Detail
| UPC | 07498300982 |
| Std. Pkg. Qty. | 1 |
| Std. Pkg. Volume (cf) | 0.0050 |
| Std. Ctn. Qty. | 0 |
| Std. Ctn. Volume (cf) | 0.0000 |
