Pan-Lug™ CT-2600/LBT Hydraulic Crimp Tool with Bluetooth®
Pan-Lug™ CT-2600/LBT Hydraulic Crimp Tool
CT-2600/LBT
Simplify your crimping tasks with our hydraulic crimp tool. Battery-powered, with Bluetooth® technology, it delivers a powerful 4-ton force to terminate large wire terminals quickly and efficiently.
Specifications
| Tool Type | Die Type |
| Maximum Aluminum Conductor Size (AWG) | 2/0 |
| Minimum Aluminum Conductor Size (AWG) | 6 |
| Maximum Copper Conductor Size (kcmil) | 300 |
| Minimum Copper Conductor Size (AWG STR) | 8 |
| Sub Brand | BlackFin™ |
| For Use With | Panduit Compression Connectors |
| Includes | 2 Rechargeable Batteries (Makita Lithium-Ion 18VDC, 4Ah), 1 Makita Battery Charger - 120VAC (with US plug configuration), 1 Tool Case |
| Crimp Force (ton) | 4 |
| Crimp Cycle Time (s) | 4 |
| Battery Charge Time (min) | 40 |
| Battery Type | Lithium-Ion |
| Insulated Tool Head | No |
| Overall Length (In.) | 4.9 |
| Overall Length (mm) | 125 |
| Overall Width (In.) | 3 |
| Overall Width (mm) | 75 |
| Overall Height (In.) | 14.2 |
| Overall Height (mm) | 360 |
| Standards Met | Meets OSHA mandated electrical and mechanical product safety requirements for Handheld Motor-Operated Electric Tools specification UL 60745-1 and CSA C22.2 No. 60745-1. |
| Product Type | Hydraulic Crimp Tool |
| Tool Configuration | In-Line Design |
| Weight (Kg) | 1.8 |
| Weight (lb) | 4 |
| Crimp Profile | Circumferential |
| Base Material | Steel |
| Battery Voltage (V) | 18 |
Runtime Graph
| Configuration |
|---|
Packaging Detail
| UPC | 61305681781 |
| Std. Pkg. Qty. | 1 |
| Std. Pkg. Volume (cf) | 3.8104 |
| Std. Ctn. Qty. | 0 |
| Std. Ctn. Volume (cf) | 0.0000 |
Resources
NOTE: Not all resources are available in your language.
If product info is not displayed in your selected language, it will be coming. We will continue to improve the experience over time.
Language
| Product Bulletins | Next Generation BlackFin Tools Product Bulletin | English | |
| Specification Sheets | Tool Specification for CT-2600/LBT | English | |
| Part Drawings | CT-2600/LBT Part Drawing | English | |
| Flyers | 5-Year Blackfin™ Tool Warranty Extends Confidence Flyer GRFL7-SA-ENG | English | |
| Manuals | CT-2600/LBT Instruction Manual HE.20216 | English |
