UPS Step-Down Transformer
UTFMRDU
Our UPS step-down transformer converts high voltage to a lower voltage for safe and efficient power distribution, ensuring reliable performance and protection for your critical equipment
Specifications
| Product Type | Step-Down Transformer |
| Region | North America |
| Phase | 1 |
| Nominal Input Voltage (V) | 208 |
| Input Frequency Range (Hz) | 50 - 60 |
| Input Plug | NEMA L6-30P |
| Input Cord Length (ft.) | 2 |
| Input Cord Length (m) | 0.6 |
| Output Capacity (kVA) | 5 |
| Output Capacity (kW) | 5 |
| Frequency Compatibility (Hz) | 50/60 |
| Nominal Output Voltage (V) | 120/208 |
| Output Receptacles | (1) L6-30R, (12) 5-20R |
| Outlet Bank Switching | No |
| Mount Orientation | Horizontal/Vertical |
| Number of Rack Units | 2 |
| Overall Width (In.) | 17.3 |
| Overall Width (mm) | 440 |
| Overall Height (In.) | 3.4 |
| Overall Height (mm) | 86.5 |
| Overall Depth (In.) | 24.4 |
| Overall Depth (mm) | 621 |
| Minimum Operating Temperature (°C) | 0 |
| Minimum Operating Temperature (°F) | 32 |
| Maximum Operating Temperature (°C) | 40 |
| Maximum Operating Temperature (°F) | 104 |
| Power Module Minimum Storage Temperature (°C) | -25 |
| Power Module Minimum Storage Temperature (°F) | -13 |
| Power Module Maximum Storage Temperature (°C) | 55 |
| Power Module Maximum Storage Temperature (°F) | 131 |
| Maximum Relative Humidity (%) | 95 |
| Minimum Relative Humidity (%) | 0 |
| Online Mode Efficiency Rating (100% Load) (%) | 97 |
| Operating Elevation (ft.) | 10000 |
| Operating Elevation (m) | 3000 |
| Audible Noise (dBA) | 45 |
| Grounding Method | Lug |
| Compliance Certifications | cUL: UL 1778 5th Edition, CSA C22.2 No.107.3-14, NoM FCC Part 15 Subpart B Class A, ANSI C63.4-2014 ROHS 2.0 ISTA Procedure 2A |
| For Use With | U05N11V, U05S11V, U06N11V, U06S11V, U10N11V, U10S11V, U05N11L, U06N11L, U10N11L |
| Part Features | 120V/208V |
Runtime Graph
| Configuration |
|---|
Packaging Detail
| UPC | 61305686128 |
| Std. Pkg. Qty. | 1 |
| Std. Pkg. Volume (cf) | 3.2593 |
| Std. Ctn. Qty. | 0 |
| Std. Ctn. Volume (cf) | 0.0000 |
