Reel Smart™ CA9 Ezair™ Terminal Applicator
Reel Smart™ CA9 Terminal Applicator, Pneumatic, PK1
CA9
Achieve high-volume terminations with our terminal applicator. Compatible with most bench-top presses and wire processing machines, its quick change die sets reduce setup time.
Specifications
| Sub Brand | Reel Smart™ |
| For Use With | CP-871, UC200, UC100, and other commercially available wire processing machines & bench presses |
| Overall Length (In.) | 10.25 |
| Overall Length (mm) | 260 |
| Overall Width (In.) | 4 |
| Overall Width (mm) | 102 |
| Overall Height (In.) | 9.25 |
| Overall Height (mm) | 235 |
| Product Type | Applicator - Reel Fed |
| Part Features | Stand is not apart of CA9 |
Runtime Graph
| Configuration |
|---|
Packaging Detail
| UPC | 07498310239 |
| Std. Pkg. Qty. | 1 |
| Std. Pkg. Volume (cf) | 0.9851 |
| Std. Ctn. Qty. | 0 |
| Std. Ctn. Volume (cf) | 0.0000 |
Resources
NOTE: Not all resources are available in your language.
If product info is not displayed in your selected language, it will be coming. We will continue to improve the experience over time.
Language
| Product Bulletins | Ferrule Installation Tools | English | |
| Videos | Video 4:3 - Product - Reel_Smart_REV_web | English | |
| Videos | Reel Smart: Install Crimp and Cutting Dies Video 16:9 CD 920-F89 | English | |
| Videos | Reel Smart: Mounting the Applicator Video 16:9 CA9 | English | |
| Part Drawings | Part Drawing - PDF - CA9-TP24490A01-00 CUST DWG | English | |
| Manuals | CA9 Applicator - Operation Manual | English | |
| Selection Guides | Selection Guide - Crimp Die Chart 2 | English | |
| Selection Guides | Terminal Material Selection Guide - SA-TMSG10 | English | |
| Technical References | CP-871 Press / CA9 Applicator Setup, Loading and Operation Quick Start Reference QS-CA9 | English |
